Key Features

• Heat sinking designed CNC aluminum housing
• 8S LiPo power capable
• Hgh efficiency design
• High-quality 4-pole sintered rotors
• Includes 6.5mm gold plated bullet connectors
• Precision ball bearings and hardened steel 8mm shaft

Overview

Perfect option for 1/5th scale models looking to run a 8S Lipo powered setup. Featuring a low cog 4-pole 8-magnet rotor design, CNC machined aluminum housing with heat sinking fins, insulated high purity copper windings, high-quality alloy steel 8mm output shaft, and high-precision bearings for high durability and smooth rotation. Preinstalled with 6.5mm gold plated bullet connectors. Perfectly matched to the Firma 160 Smart ESC.

Needed to Complete

• Electronic Speed Control such as the Firma 160 Smart ESC

What’s in the box?

• Spektrum Firma 5613-780Kv Sensorless 1/5 Brushless Motor with 6.5mm Gold Plated Bullet Connectors

Untitled Document Compatible Products Spektrum Firma Brushless Motor, 780Kv: 6.5mm Bullet SPMXSM1100 is compatible with LOS05020T1, LOS05020T2

Firma 780Kv Brushless Motor Specfications:

• Bearings or Bushings: : Bearings
• Cells: : 4-8S LiPo
• Connector Type: : 6.5mm Bullet,6.5mm Bullet
• Efficiency: : 90%
• Input Voltage: : 12-35.2V
• Maximum Continuous Current: : 200A
• Motor Type: : Brushless
• Number of Poles: : 4
• Output: : 7000W
• Overall Diameter: : 2.2″ (56mm)
• Overall Length: : 4.4″ (113mm)
• RPM/Volt (Kv): : 780Kv
• Recommended Speed Control: : Spektrum Firma 160 Smart ESC
• Shaft Diameter: : 5/16″ (8mm)
• Size: : 3660
• Weight: : 43oz (1220g)
• Wire Gauge: : 10 AWG

Spec

• Brand: Spektrum
• Part No: SPMXSM1100
• Barcode: 0605482428085
• Fitment: Option Part
• Fitment: Standard Part
